Bearing Detail
| Dimension | 9500-16500*2500-3000*3200 (can be customized) |
| Tare weight | 8000kg-12800kg |
| Capacity | 3 ton -100 ton |
| Main beam | Q690 steel |
| Side beam | 16 mm-25 mm High-strength plate bending |
| Platform | 3mm-5mm thickness chequered plate or can be optional |
| Ladder | Manual type or Hydraulic type |
| Axle | 13/16T, FUWA/BPW/CTC brand etc |
| King pin | 2.0 or 3.5 inch bolted type |
| Suspension | Mechanical suspension/Germany type or America type/Air suspension |
| Leaf spring | 90 mm*13 mm*10 layer or 100 mm*12 mm*12 layer |
| Braking system | WABCO 6 relay valve, spring brake chamber, 2 pieces of 45L air tank |
| Rim | 9.0*22.5/8.0-20/8.5-20 |
| Tire | Multiple options available (8.25R20, 11.00R22.5, etc.) |
| ABS | Optional |
| Spare tire carrier | 2 pieces |
| Painting | 1 layer anti-corrosion primer, 2 layers paint |
Purpose of trailers
Cargo transportation: It can load a large amount of cargo, reduce transportation costs, and improve transportation efficiency. It is widely used in long-distance transportation and bulk cargo transportation.
Accident rescue: As a professional type of trailer, road tow trucks are used for traffic accident rescue. They can tow, lift, and lift faulty vehicles to quickly restore traffic order.
Family travel and outdoor adventure: Travel trailers provide convenience for family travel and outdoor adventures. They can carry a large amount of equipment and supplies and provide comfortable living space.
Industrial and agricultural production: In industrial production, they are used to transport raw materials and finished products; in the agricultural field, they are used to transport agricultural products and equipment.
Types of trailers
Flatbed trailer: Widely used in logistics, construction sites, and ports. Tonnage is generally 3t-25t.
Agricultural trailer: Pulled by a tractor, suitable for agricultural production and transportation. Tonnage is generally 2t-10t.
Car/construction vehicle trailer: Used to tow cars or construction machinery, tractor + trailer type.
Dump trailer: Equipped with a hydraulic jack for automatic unloading, available in rear-flip or side-flip configurations.
Travel trailer: RV-type trailer with living facilities for camping and tourism.
Small/micro trailers: Includes livestock, motorcycle, boat, and luggage trailers, lightweight and practical.
Classification
Classification by purpose:
Highway trailer: Mainly for towing faulty or accident vehicles.
Industrial trailer: Used in factories and warehouses for internal transport.
Agricultural trailer: For towing agricultural machinery and produce.
Special trailer: Designed for specific needs like fire rescue or mobile stages.
Classification by structure:
Flatbed trailer: Open cargo platform for large equipment.
Box trailer: Enclosed compartment to protect goods from weather.
Tank trailer: Designed for transporting bulk liquids and gases.
Parameters
Towing capacity: Indicates the maximum weight the trailer can safely tow, depending on engine, frame, and tire capability.
Load capacity: The weight of the cargo the trailer can carry, affected by frame strength and suspension.
Wheelbase: Distance between wheels, crucial for stability and passability.
Carriage size: Dimensions determine cargo space and transportation efficiency.
Frequently Asked Questions
Q1: Can the trailer dimensions be customized?
Yes, the dimensions of our trailers can be customized to meet your specific transportation requirements.
Q2: What is the load capacity of these trailers?
We offer trailers with varying load capacities, typically ranging from 3 tons to 100 tons depending on the model and application.
Q3: What types of suspension systems are available?
We provide options including mechanical suspension, Germany-style suspension, America-style suspension, and air suspension systems.
Q4: Are these trailers suitable for off-road or construction sites?
Yes, our industrial and flatbed trailers are designed for durability and are suitable for construction sites, mines, and logistics environments.
Q5: What kind of painting is used to prevent rust?
Our trailers are finished with one layer of anti-corrosion primer and two layers of high-quality paint to ensure durability against environmental factors.
Q6: Do the trailers come with an ABS system?
Yes, the ABS braking system is available as an optional feature to enhance safety during operation.
