| Dimensions(LxWxH) | 8500x2500x1500mm (Beam height 420mm) |
| Tare Weight | 4800kg |
| Loading Capacity | 25T |
| Suspension | America type mechanical Suspension |
| Leaf spring | 10pcs*90*13mm |
| Tire | 12R22.5 double star brand 8pcs |
| Wheel rim | 9.0-22.5 better brand 8pcs |
| Turntable | Diameter 1100mm |
| Traction hook | DN50 |
| Traction bar | Length 1.4m |
| Main beam material | Q345 |
| Platform plate | 3mm Diamond Plate |
| Braking system | WABCO RE6 relay valve; T30/30 chamber; 40L air tanks |
| ABS | Optional |
| Lights | LED 8 side lights, 2 rear lights, 2 width lamps |
| Painting | Sand blasting, 1 coat anticorrosive prime, 2 coats final paint |
| Accessories | Tool box, spare tire carrier, crank, shaft head wrench |
| Water tank | Customizable size |
01Powerful traction: Equipped with high-power engines and high-performance transmission systems for towing heavy loads.
02Good stability: Designed with a lower center of gravity and wider wheelbase, plus advanced suspension for stable driving.
03Flexible maneuverability: Optimized steering systems allow for easy control even in narrow or complex environments.
04Reliable braking system: High-performance drum or disc brakes with auxiliary braking systems ensure effective stopping.
Transportation: Used for long-distance logistics, container transport, and urban road maintenance.
Engineering construction: Ideal for hauling building materials, excavators, bulldozers, and heavy mechanical equipment.
Rescue operations: Essential for clearing accident sites, towing faulty vehicles, and disaster response.
Military field: Used for transporting weapons, ammunition, supplies, and heavy artillery with high mobility.
