| Item No. | 32218 (Metric) |
| Bearing Type | Taper roller bearing (Metric) |
| Material | Chrome steel GCr15 |
| Specification | 90*160*42.5 |
| Precision | P0,P2,P5,P6,P4 |
| Inner Ring Width | 40 mm |
| Outer Ring width | 34 mm |
| Contact angle | 15.642° |
| Basic rated dynamic load | 309kN |
| Basic rated static load | 340kN |
| Reference speed | 3400r/min |
| Limiting speed | 4000r/min |
| Clearance | C0,C2,C3,C4,C5 |
| Brand | JITO or OEM |
| Separable | Yes |
| Application | Automobiles, rolling mills, mining, metallurgy, plastic machinery and other industries |
| Bearing Package | Pallet, wooden case, commercial packaging or as customers' requirement |
Strong bearing capacity: Mainly bears radial and axial combined loads dominated by radial loads, and generally does not bear axial loads alone.
Separable installation: The inner and outer rings can be installed separately, and the axial clearance and radial clearance can be adjusted during the installation process, or pre-interference installation can be performed.
Axial displacement limit: It can limit the axial displacement of the shaft or the housing, and does not allow the shaft to be tilted relative to the housing or the hole.
Clearance affects life: The size of the axial clearance of the tapered roller bearing directly affects the service life of the bearing.
Machine tool industry: Used in the spindle, feed shaft and other parts of the machine tool, bearing cutting force and rotation load, ensuring the accuracy and stability of the machine tool.
Automotive industry: Applied to the wheel hub, differential, transmission and other parts of the car, supporting the rotation of the wheel, transmitting power and torque.
Reducer industry: Supporting the gear shaft in the reducer, bearing the radial and axial forces generated during gear transmission, and ensuring the normal operation of the reducer.
Mining machinery: In equipment such as crushers and ball mills, tapered roller bearings are used to support rotating parts and bear huge impact loads and radial loads.
Metallurgical industry: In various equipment of rolling mills and steel mills, it is used to withstand rolling force and axial force to ensure stable operation of the equipment.
We work with customers to find the optimum solution based on their specific demand and operating conditions.
Following ISO standards, our professional staff and testing instruments ensure quality from raw material to finished product.
Standardized export packing and custom packaging options, including boxes and labels, are available upon request.
We provide various shipping solutions including ocean, air, and express freight depending on your specific requirements.
All bearings come with a 12-month warranty from the shipping date against defects in material and workmanship.
